Recovery Board Mounting Bracket (set)

Original price $220.00 - Original price $220.00
Original price
$220.00
$220.00 - $220.00
Current price $220.00

Comes as a set of 2

Recovery Board Bracket Installation Guide

  • Ask a friend or family member to hold the Recovery Boards in the exact position where you want to fix it. Fit the threaded plastic discs to two selected holes and let them seat on the body of your vehicle.
  • Consider the characteristics of your vehicle before choosing where to put the holes and decide how you want to position the Boards—transversally, horizontally, or asymmetrically.
  • Mark the middle bores of the two threaded plastic discs on the body surface with a felt-tip pen.
  • Drill two holes (12 mm in diameter) on the body sheet. If the inner side is fitted with some upholstery that you do not want to drill in, take it off before drilling.
  • Put the screws with a base plate into the bores; wind the two threaded plastic discs on them from outside and draw them home. Use a standard angle grinder wrench. If you removed the upholstery on the inner side, put it back.
  • Put the Recovery Boards on the screws, fit the plastic cover discs, and tighten up the security nuts with your hand.
  • If everything is correctly seated, mark or measure where the bolts will have to be cut off.
  • Wind off the security nuts and take off the recovery boards. Cut the screws with a saw or angle grinder and deburr the cut ends.
  • Now you can install the boards permanently. Tighten the security nuts approximately as strong as when you mount the cutting disc in the angle grinder.
